KD69
Specification & Download Purchase
Specification
  • OS

    RTOS

  • Processor

    ARM Cortex-A5

  • Secure Processor

    KD69-None

    KD69R, KD69P-231g

  • Memory

    RAM 8MB+Flash 12MB

    Support flash extend up to 64MB



  • NFC Contactless

    KD69-None

    KD69R, KD69P-EMV Contactless, NFC Tag

  • IC Contact

    KD69-None

    KD69R-None

    KD69P-EMV Chip & PIN

  • LED Indicator

    1*RGB LED, Power and Status indicator

  • Rear LCD

    2.3", Color Screen, 284*76

  • Front LCD

    KD69-2.8", Color Screen, 320*240

    KD69R, KD69P-2.8", Color Screen, 320*240(DQR), 2.3", Color Screen, 284*76(SQR)

  • Ports

    1*Micro SIM, USB Type C

  • Battery

    3.7V/2600mAh

  • Com.

    4G Cat1, Wi-Fi(Optional)

  • Keypad

    5*Keys（PWK，Vol±，FN，Reset）

    Physical keypad(0~9+5*FNs)

  • Audio

    Speaker 4Ω&3W

  • Power

    DC5.0V/1.0A

  • Environmental

    Operating Temperature: -10°C to 50°C

    Storage Temperature: -20°C to 60°C

    Relative Humidity : 5% to 95%(Non-Condensing)

  • Certifications

    KD69-CE, FCC, RoHS

    KD69R, KD69P-PCI PTS 6.x&7, EMV L1&L2, EMV CL L1, Mastercard Paypass, Visa Paywave, JCB J/Speedy, Amex Expresspay, Discover D-PAS, UnionPay QuickPass, RuPay, MCCS, Mastercard TQM, FCC, CE, BIS, WPC, RoHS

  • Dimensions

    103.8mm L×88.1mm W×153.2mm H

  • Weight

    KD69-257g

    KD69R-274g

    KD69P-278g
