Android 14

Qualcomm Quad-core Cortex-A53, 2.0GHz

3.5" HVGA (320 × 480) Color LCD, Capacitive Touch

(UN10 / UN10P)

2.36" (76 × 284) Color LCD (UN10R / UN10RS)

2GB RAM +16GB ROM

4G/3G/2G+WiFi 2.4GHz/5GHz,

802.11 a/b/g/n/ac +BT5.0

(Optional：Ethernet 10/100)

GPS, GLONASS, Galileo, BeiDou

Contactless Cards (UN10 / UN10R / UN10RS)

Chip Cards + Contactless Cards (UN10P)

1 × SIM + 2 × SAM (UN10 / UN10P / UN10R)

Optional：1 × SIM + 2 × SAM + eSIM (UN10 / UN10P / UN10R)

Optional：1 × SIM + 4 × SAM (UN10 / UN10P / UN10R)

1 × SIM + eSIM (UN10RS)

Optional：1 ×SAM + eSIM (UN10RS)

Front: 2 MP, FF (UN10 / UN10P)

1 x Microphone,

1 × Speaker,

1 × Audio Jack

Ambient Light Sensor, Infrared Sensor

UN10/UN10P/UN10R：1 x USB Type-C (Slave), 1 x USB Type-A (Host),

1 x MDB Slave,1 x RS232(RJ45), 1 x Digital I/O, 1 x LAN（RJ45）,

1x DC Power Port

UN10RS：1 x USB Type-C (Slave), 1 x MDB Slave,

1 x LAN（RJ45）, 1 x DC Power Port

IP66 / IK10 (UN10)

IP65 / IK10 (UN10P)

IP66 / IK09 (UN10R / UN10RS)

DC 5V/3A Via USB-C or DC Power Port, DC 7V-48V Via MDB

75.8mm (L) × 121.8mm (W) × 48mm (H)

(UN10 / UN10P / UN10R)

75.8mm × 121.8mm × 24mm (UN10RS)

Mounting Bracket, External 4G Antenna (Optional：Power Adapter)

PCI 7.x, EMV L1, EMV CL1,Quickpass, Paypass, Paywave,

TQM, JCB, Discover, AMEX, IP66, IK10, CE, FCC, RoHS

Operating: -20°C to 70°C (UN10 / UN10P)

Operating: -20°C to 60°C (UN10R / UN10RS)

Storage: -30°C to 80°C

Humidity: 5% to 95% (Non-Condensing)

Operating Temperature : -20°C to 70°C

Relative Humidity : 5% to 95%(Non-Condensing)
