EF910
Specification & Download Purchase
Specification
  • OS

    Android 11

  • Printer

    High Speed Thermal Printer, Paper

    Roll Width : 80mm, Diameter: 58mm

    Support Automatic Cutter

  • Audio

    Built-in Speaker

  • Adaptor

    AC:100-240V

    DC:12V-5A

  • Processor

    Cortex Quad-core

    A55, 2.0GHz

  • Card Readers

    NFC Reader

    Type A

  • Keys

    1 Power Key

  • Physical

    430mm (L) x 290mm(W) x 490mm(H)

  • Memory

    2GB RAM + 16GB ROM

    4GB RAM + 64GB ROM(Optional)

    (Micro SD Card Supported up to 128GB)

  • Communication

    Wi-Fi, 802.11a/b/g/n/ac, 2.4GHz&5GHz

    BT 4.0

    LAN 1000M

  • Environmental

    Operating Temperature: -10°C to 50°C

    Storage Temperature: -20°C to 60°C

    Relative Humidity : 5% to 95%(Non-Condensing)

  • Display

    15.6" Touch + 15.6" Display

    15.6" Touch + 11.6" Display(Optional)

    15.6" Touch + 8-digit LED(Optional)

  • Ports

    2 x USB 2.0，1 x USB 3.0，1 x USB OTG

    1 x RS232,1 x RJ11

    1 x RJ45

    1 x SIM Card，1 x SD Card

    1 x DC

  • Cameras

    Built-in camera 2 MP(Optional)

    Binocular camera 2 MP(Optional)

  • Certifications
    3C, CE, RoHS
  • Accessories (Optional)
    Scanning Module
